JUKI MS-1261 SERIES


No.1 Quality
Service

1 Year
Warranty

EMI
Option
Category:

Description

The placement of the feed mechanism has been charged to decrease the feed amount when the needle enters the material, thus preventing the needle from bending. The bobbin thread is clamped without fail, thereby producing consistent thread loops.The looper tucks the needle thread without fail, thereby finishing uniform seams.

The number of teeth of the feed dog has been increased so that it can easily catch overlapping material. The shape of the presser foot has been modified to prevent single-sided contact with the overlapped part. The movable needle guard (rear) is provided with a vertical adjusting mechanism. These features contribute to smoother feed of heavy-weight materials, thereby preventing stitch skipping.

Features

The machine is the leading doublechainstitch machine for heavy-weightmaterials and achieves higherefficiency in operation and higherquality of finished products.

Specification

Model name MS-1261M/(with V045) MS-1261/(with V045)
Application Medium- to heavy-weight Extra heavy-weight
Max. sewing speed 3,600sti/min
Needle gauge 5.6mm (7/32″)~9.6mm (3/8″)
Stitch length 1.4~4.2mm
Needle UY128GAS-NY (#19) #16~#22
UY128GAS (Nm120) Nm100~Nm140
UY128GAS-NY (#21) #16~#22
UY128GAS (Nm130) Nm100~Nm140
